Microscope

Microscope Type

Converging stereoscope microscope

Magnification selection

two steps magnifications

Eyepiece

10X

Magnification Ratio (Field of view)

10X(18mm),16X(14.5mm)

Pupillary Adjustment

50mm ~ 82mm

Diopter Adjustment

± 5D

Base

Side Shift

110mm

Depth shift

90mm

Height shift

30mm

Chin rest

Height Shift

80mm

Fixation Target

Red LED

Illumination system

Slit Width

0 ~ 9 mm Continuous ( at 9mm , slit becomes a circle )

Slit Height

0 ~ 8mm Continuous

Slit Angle

0°  ~ 180°  adjustable

Slit Inclination

0°  ~  23 °

Diameter of Light Spot

Ø10mm, Ø7mm , Ø5mm, Ø3mm, Ø2mm, Ø1mm, Ø0.2mm

Filter

Heat Absorption , Grey , Red-Free , Cobalt Blue

Illumination Bulb

12v  50w  halogen lamp

Power

Input Voltage

110V / 220V AC

Frequency

50 / 60 HZ

Power Consumption

68 VA

Weight and Size

Gross Weight

18kg

Dimension

690mm(L) × 440mm(W) × 420mm (H)
