Basic

Intraocular pressure

(IOP) measuring range

1mmHg~ 30mmHg /1mmHg ~ 60mmHg

( precision of 1mmHg)

Measuring system

Dual sensor system of light and pressure

Working distance

≥11mm

R/L

Automatic detection and display

Measuring result

10 times per eye; 3 times result printing per eye

Recording

Build-in printer

Measuring mode

Auto/Manual

Focus

When luminous spot is in the focus frame, 2 modes can be chosen.

Auto mode : auto intraocular pressure measurement

Manual mode : when it's good focus, the frame will turn yellow

into green, and click to start the measurement

Error indication

If the measurement signal is weak, the IOP will be enclosed by(),

or display "ERR ”

Safety limit button

Install measurement for minimum distance between head and patient

Safety functions

The distance between air nozzle and cornea is controlled in

preset range(such as 11mm); Iit will stop going forward when

the cornea is too closed to air head.

Movement range

≥30mm(front to back)/ 90mm(left to right)/ 30mm(vertical)

Jaw layer vertical

movement

0~ 65mm with under jaw layer

Display mode

10.1-inch HDMI color LED touch monitor

Output port

USB2.0

Working platform

Electric elevating platform

Others

Size

380 mm (L) x 460mm (W) X 505mm (H)

Weight

19.7kg

Power supply

220V/50Hz
